SPECIFICATION



Brand: DIXON

            Body-Cast Iron to BS 1561

• Material: Valve - Copper Alloy to BS 1982

                  Hand Wheel - Cast Iron to BS EN 1561

• Inlet: 4" BS 4504

• Outlet: 336 Female Instantaneous

• Flange: (4") 100mm Table E BS 10

• Working Pressure: 16 bar

• Test Pressure: 22.5 bar

• Finishing: Red and Yellow (Optional)

• Applicable Standards: BS 5041-1:1987



APPLICATION

Wet Outdoor fire hydrant is a water supply facility connected with fire-fighting system network outside building. It is used to supply water for fire engines from municipal water supply network or outdoor water network where no danger of Vehicle accidents or freezing atmospheres. It is better to be used in malls, shopping centers, colleges, hospitals, etc. It can also be connected to nozzles to prevent fire.
